Cover Plate
Technical Parameter
Sloped Flange Cover
Material: AISI304, AISI316, Duplex 2205
Surface: Satin, Mirror, Powder Coating, PVD
| Code | φ(mm) | D(mm) | H(mm) | Wall(mm) |
| A60034 | 33.7 | 85 | 12 | 0.8 |
| A60042 | 42.4 | 85 | 12 | 1.0 |
| A60142 | 42.4 | 105 | 18 | 1.5 |
| A60148 | 48.3 | 105 | 18 | 1.5 |
| A60143 | 43.0 | 105 | 18 | 1.5 |
| A60242 | 42.4 | 105 | 25 | 1.5 |
| A60248 | 48.3 | 105 | 25 | 1.5 |
| A60348 | 49.0 | 110 | 18 | 1.5 |
| A60350 | 50.0 | 110 | 18 | 1.5 |
| A60448 | 49.0 | 110 | 20 | 1.5 |
| A61842 | 42.4 | 110 | 27 | 1.5 |
| A60542 | 42.4 | 110 | 27 | 4.0 |
| A60648 | 48.3 | 120 | 27 | 4.0 |
| A60742 | 42.4 | 125 | 18 | 1.5 |
| A60748 | 48.3 | 125 | 18 | 1.5 |
| A60743 | 43.0 | 125 | 18 | 1.5 |
| A60750 | 50.8(2″) | 125 | 18 | 1.5 |
| A60850 | 50.8(2″) | 128 | 15 | 1.0 |
